固定电阻器 Fixed Resistors
| Product | Appearance | Part NO. Overview |
Power ratings (W) |
Resistance range(Ω) |
Details | |
|---|---|---|---|---|---|---|
| P.C.B Mounting type |  |
|
1～10 | 0.1～2.7K | |
|
 |
KNT KNP 1～3W Taping type |
1～3 | 0.1～150 | |
||
 |
|
2～10 | 0.1～1.8K | |
||
 |
KNX Direct-mounting,space saving type |
5～20 | 0.33～3.9K | |
||
 |
PRX Thick Film Power Resistor |
35 (on flange) |
20～1M | |
||
 |
SMW/SMF Power Surface Mounting Type Resistor |
1～3 | SMW: 0.1～500 SMF: 10～2M |
|
||
 |
RSN/RSS Non Flammable Metal Oxide Film Resistor |
RSN: 1/2～2 RSS: 1/2～2 |
RSN: 0.22～100K RSS: 0.22～50K |
|
||
 |
RSU Ultra mini size Non Flammable Metal Oxide Film Resistor |
1, 2 | 0.22～1M | |
||
| Square Cement type |  |
SQP Axial lead type |
3～20 | 0.12～4.7K | |
|
 |
SQY Direct-mounting type |
5～15 | 0.18～3.3K | |
||
 |
SQH Horn terminal type |
20～40 | 1.0～8.2K | |
||
 |
SQM/SPS Radial lead type |
SQM: 1～10 SPS: 7,10 |
SQM: 0.1～80K SPS: 0.1～60K |
|
||
 |
SQF Non Flammable Square Fixed Resistor with Thermal Fuse |
1.6～3.5 | 0.1～50K | |
||
| Shunt Resistors |  |
SV Shunt resistor for detecting current |
10 | 10～100m | |
|
 |
WOR Shunt resistor for detecting current |
3～14A | 4～75m | |
||
 |
POR101 Shunt resistor for detecting current |
30A | 1m | |
||
 |
SBA Current sensing SMD Shunt Resistor |
See Details | See Details | |
||
 |
SBB Current sensing SMD Shunt Resistor |
See Details | See Details | |
||
 |
SBC Current sensing SMD Shunt Resistor |
See Details | See Details | |
||
 |
SBF Current sensing SMD Shunt Resistor |
See Details | See Details | |
||
 |
SBG Current sensing SMD Shunt Resistor |
See Details | See Details | |
||
 |
SBZ Large Current Sensing Shunt Resistor |
36 | 0.05～1m | |
||
| Precision Resistors |  |
SL Precision type |
2～10 | 0.1～50K | |
|
| Power type Resistor |  |
|
5～400 | 1～400K | |
|
 |
|
120～600 | 0.02～20 | |
||
 |
ZGA Flat type |
10～95 | 0.2～80K | |
||
| Metal-Clad Fixed Resistors |  |
FH Compact and light power type |
6～50 | 0.01～40K | |
|
 |
RH Compact and high power type |
30～200 | 0.07～80K | |
||
 |
SMR High power type |
60～220 | 0.1～20K | |
||
 |
SML High power type |
150～800 | 0.22～36K | |
||
 |
SMV High power type |
60～1,000 | 0.5～5K | |
||
 |
TT High Power ･ Thin type |
70～240 (with Fan) |
1～100 | |
||
| Film Resistors |  |
HM High voltage and super high resistance value type |
1～100 | 100K≦R＜250M | |
|
| Customized Resistor for automotive applications |  |
|
||||
